23.1inch Shelf Edge LCD Display (Model-DXE231)

Description

14.5mm Thin. 700 cd/m² Bright. The 23.1″ Shelf Edge Display Built for 600mm Retail Fixtures.

The DXE231 is DNR Display’s flagship shelf-edge display — 0.75kg, 14.5mm thin, and engineered to fit standard 600mm retail shelf modules without modification. At 700 cd/m², it’s the brightest display in the DNR Display range. Wi-Fi 6, Android 11, CMS-managed, optional capacitive touch, and a 7-day lead time.



Built to fit. Not to be fitted.

Retail shelving runs on standard module widths — 600mm being the most common internationally. The DXE231 is designed specifically for this format: 597.2mm wide, slotting into 600mm shelf modules without bracket modification, custom cutting, or fixture redesign. For a multi-store rollout, that means one display spec works across the estate wherever 600mm shelving is in place.

The brightest display in the range — by a meaningful margin

At 700 cd/m², the DXE231 is brighter than every other display in the DNR Display lineup, including the 500 cd/m² DSF330 and DTB286. In retail environments with strong overhead lighting, reflective packaging, and competing visual noise, that brightness difference is the difference between a display that gets noticed and one that gets lost in the shelf.

Light enough to forget it’s there — until it’s on

At 0.75kg and 14.5mm thick, the DXE231 is the lightest, thinnest display in the range. It mounts directly onto shelf rails using standard brackets, adds negligible weight to the fixture, and sits flush enough not to interfere with product placement or sightlines. Installation is fast because there’s nothing to reinforce, redesign, or work around.

From display to interaction — when you need it

The DXE231 is available with optional capacitive touch, converting the shelf edge from a passive promotional display into an interactive tool. Shoppers can tap to check stock, compare variants, or access detailed product information — without changing the display’s footprint or mounting. Specify touch from the outset, or standardise on the non-touch model and upgrade selected high-traffic locations later.

Built for the full retail estate

Wi-Fi 6 and Bluetooth provide reliable connectivity even in dense, multi-device retail networks. At under 20W, running cost across a large estate is minimal. Android 11 (with Android 8.1 also available) and CMS software manage content across every unit from a single dashboard. 30,000+ hour lifespan, CE/RoHS/FCC certified, 7-day lead time.

Specification summary

• 1″ shelf edge display, 597.2 × 61.8 × 15mm, 0.75kg
• 1920×158 resolution, 700 cd/m² brightness, 89°/89°/89°/89° viewing angles
• Android 11 (8.1 also available), 2GB RAM, 32GB ROM (64GB optional)
• Optional capacitive touch
• Wi-Fi 6 (2.4/5GHz) + Bluetooth, CMS and AIoT software support
• Operating: 0°C to 45°C | Storage: −20°C to 60°C
• Under 20W | 30,000+ hour lifespan
• CE, RoHS, FCC certified | OEM/ODM supported | 7-day lead time



Specifications

---



Size	23.1″ LCD panel
Weight	0.75 kg
Dimensions	597.2 × 61.8 × 15 mm
Active Area	585.22(H) ×48.16(V)mm
OS	Android 8.1/11
RAM	2G DDR4
ROM	32G  EMMC(64G EMMC for optional)
Memory Extension	TF card extension with the highest support for 64GB
Resolution	1920*158[RGB], 83PPI
Viewing Angles	89°/89°/89°/89° [Typ.][CR>10]
Frequency	60Hz
Brightness	700cd/㎡
Interfaces	1*micro USB(OTG), 1*TF card, 1*Type-C
Display Color	16.7M, 72%NTSC
Backlight	WLED
Internet	Support 2.4/5G WIFI6 connection + BT
Storage Environment	Temperature：-20℃～60℃ Humidity：5%～95% Atmospheric Pressure：86kPa～104kPa
Working Environment	Temperature：0℃～45℃ Humidity：10%～85% Atmospheric Pressure：86KPa～104KPa
Operating Voltage	100-240V(50/60Hz)
Power Consumption	<20W
Software	Support CMS software and AIoT interactive software
Certifications	CE/ RoHS/ FCC
Lifespan	≥30000 hours
Optional Configuration	Capacitive Touch



Got 600mm shelving? The DXE231 was made for it.
