24-inch Double-sided Stretched Bar LCD Screen (Model-DSB240-DS)

Description

24-inch Double-sided Stretched Bar LCD Screen (Model-DSB240-DS)

The DSB240-DS hangs above the aisle and broadcasts simultaneously to shoppers on both sides — in a unit just 137mm tall and 5.5kg. The ultra-wide 1920×360 format fits shelf edges, gondola tops, and overhead corridors that standard displays can’t reach. Dual-band Wi-Fi, Android 11, CMS-managed, and shipping in 7 days.



The display that lives where the shopper is.

The DSB240-DS is built for the narrow, high-traffic spaces where standard signage can’t go. At 617.5mm wide and only 137mm tall, it mounts above shelf edges, along gondola tops, across doorframes, and in ceiling-hung aisle configurations — right at the point where a buying decision gets made. And because both faces broadcast simultaneously, every shopper in the aisle sees it, regardless of which direction they’re walking.

Half the hardware. Double the reach.

Single-sided displays require two units to cover both sides of an aisle. The DSB240-DS does it with one — halving the hardware cost, the installation time, the cabling, and the ongoing management overhead. Each face runs independently, so you can serve the same content on both sides or tailor it by direction: incoming shoppers see a promotional offer, outgoing shoppers see a loyalty prompt.

Built for the full retail temperature range

Most digital signage starts operating at 0°C. The DSB240-DS works down to −10°C — which means it performs in refrigerated aisles, chilled drink sections, and cold-chain retail environments where standard displays fail. The 30,000+ hour backlight lifespan and commercial-grade IPS panel are built for continuous use in demanding conditions.

Managed remotely, updated instantly

Android 11 and CMS software handle content scheduling, updates, and monitoring across every unit in a deployment from a single dashboard. Dual-band Wi-Fi (2.4GHz and 5GHz) keeps connectivity reliable in busy retail networks where channel congestion is common. And with a 7-day lead time — the shortest in the DNR Display range — new deployments move fast.

Specification summary

• 24″ double-sided stretched bar, 1920×360, 597.89×112.1mm active area
• 300 cd/m² brightness, 178° viewing angles (H and V)
• 30,000+ hour lifespan
• Android 11.0, 2GB RAM, 32GB ROM (64GB optional)
• Dual-band Wi-Fi 2.4/5GHz, CMS and AIoT software support
• Operating: −10°C to 50°C | Storage: −20°C to 60°C
• 2×USB, HDMI out, RJ45, TF card | Under 40W
• CE, RoHS, FCC certified | OEM/ODM supported | 7-day lead time



Specifications

---



Weight	5.5 kg
Dimensions	617.5 × 137 × 27.2 mm
Active Area	597.89(H) ×112.1(V)mm
OS	Android 11.0
RAM	2G DDR4
ROM	32G EMMC(64G EMMC for optional)
Resolution	1920*360
Viewing Angles	178°(H) * 178°(V)
Brightness	300cd/㎡
Interfaces	2*USB, 1*DC, 1*HDMI Out, 1*RJ45, 1*TF card
Display Color	1.07B
Internet	Support 2.4/5G WIFI connection
Storage Environment	Temperature：-20℃～60℃ Humidity：5%～95% Atmospheric Pressure：86kPa～104kPa
Working Environment	Temperature：-10℃～50℃ Humidity：10%～85% Atmospheric Pressure：86KPa～104KPa
Operating Voltage	100-240V(50/60Hz)
Power Consumption	<40W
Software	Support CMS software and AIoT interactive software
Certifications	CE/ RoHS/ FCC
Lifespan	30000+ hours

---
