55inch LCD Screen Video Wall (Model-DPV550)
Provides a variety of display modes, which can realize window roaming, window overlay, zoom, out-of-picture tiling, picture-in-picture, window perspective and other functions, and preset multiple modes, and users can define the pre-stored modes by themselves. The external splicing processor gives flexible picture switching, coupled with the high-definition seamless LCD screen attributes, bringing people a visual effect that is constantly soaring. 0mm seamless splicing adopts distributed centralized external splicing processor, single screen 4 divisions, each signal input can open the window, support single screen display, full screen display, combined screen display, can open the window at will, and can realize the picture The picture and the controller support RJ45 serial port control, IPAD control, and echo function, so that the pictures displayed on a single screen or in any combination are immersive.
Share Our Solution With Your Network
Description
55-inch LCD Screen Video Wall (Model-DPV550)
Application scenarios: shopping mall / supermarket / flagship store / retail store / pharmacy / restaurant / luxury store / airport / station / bus / metro / smart street light / bank / hospital / POP display / casino / furniture / gym / hotel / exhibition
| Size | 55inch |
|---|---|
| Dimensions | 1211.5 × 683 × 115 mm |
| Active Area | 1209.6(H) × 680.4(V)mm |
| Physical Seam | 0mm or 1.8mm or 3.5mm or 5.3mm |
| Contrast | 3500:1 |
| Color | 16.7M |
| Resolution | 1920*1080 |
| Response Time | 5ms |
| Brightness | 450~700cd/㎡ |
| Interfaces | 1*HDMI/ 1*VGA/ 1*DVI/ 1*AV-IN/ 1*AV-OUT/ 2*RS232-IN/ 1*RS232-OUT |
| Viewing Angles | 178°(H) X 178°(V) |
| Ratio | 16:9 |
| Storage Environment | Temperature:-10℃~60℃ Humidity:5%~95% Atmospheric Pressure:86kPa~104kPa |
| Working Environment | Temperature:0℃~50℃ Humidity:10%~90% Atmospheric Pressure:86KPa~104KPa |
| Operating Voltage | 100-240V(50/60Hz) |
| Power Consumption | <280W |
| DNR | OK |
| Certifications | CE/ RoHS/ FCC |
Your valuable inquiry for “55-inch LCD Screen Video Wall (Model-DPV550)” is vitally important to us!
Your comments will be dealt with at director level and kept strictly confidential. Please fill in the form below, and we will contact you as soon as possible.
Additional information
| Customized Service | Support |
|---|---|
| OEM& ODM | Support |
| Package Size | TBD |
| Package | TBD |
| Gross Weight | 24kg/Carton |
| Delivery | By Express/ By Air/ By Sea |
| Lead Time | 21 days |
